HI series Holographic Invisible Screen Price:¥

Holographic Invisible Screen
Latest Holographic Transparent LED Display
Ultra Thin and Lightweight
With Portable Carriage
Without Visible Frame and Bars
Up to 90% Visibility
Support Different Installation

Online inquiry
Detailed content Specification parameter Product packaging

Perfect Structure

Holographic Invisible Screen support different sizes: 250x1000mm and 250x1200mm.

The pixel pitch is P3.91/3.91 and P6.25/6.25 (horizontal / vertical)


Ultra Thin and Light

Professional aesthetic design, thin and beautiful. The weight is only 5KG/.

Screen thickness is 1.7MM, which can be seamless surface mount. Mounted on transparent glass.

Holographic Invisible Screen 11.png


Get In Touch !

Excellent Quality

Perfectly designed with highly transparent and high-temperature resistant high-end material light panels, it can easily achieve a permeability of up to 90%.
The whole body is mounted without a dragon frame, and the screen body can be assembled left and right, up and down, and a display height or width of
 2.4-3 meters can be achieved.
The products are used in indoor and outdoor scenes such as commercial showcases and glass curtain walls.


Key Features

Transparent and Excellent Image

Equally spaced pixel arrangement, higher definition picture quality; static scanning with integrated lamp driver.

The picture is more stable; 16bit gray scale, the color is more delicate.



High Light & High Contrast

9000:1 high contrast ratio, 5000cd/m² high brightness. Colorful and eye-catching.


Application


-Retail: Shopping mall atriums, catering & retail shop Windows

-Business activities: conference rooms, trade fairs, concerts, events

-Interactive entertainment: enterprise building, 4s shop, playground, airport, high-speed rail





Pixel Pitch (mm)
 (horizontal / vertical)
2.5/2.53.91/3.916.25/6.2510  / 10
Pixel Density (dot/m2)160000655362560010000
Transparency Rate70%80%90%94%
Display Dimension
 (mm) (w*h)
1125x1000/125x1175250x1000/250x1171/250x1468250x1175/250x1475250x1000
 Profile Dimension
(mm) (w*h)
125x1025/125x1200250x1025/250x1200/250x1500250x1200/250x1500250x1000
Resolution (dot) (w*h)50x400/50x47064x256/64x300/64x37640x188/40x23625x100
Brightness(cd/m2)≥1200≥3000≥5000≥4000
Weight (kg/set)6.5654.8
Scanning ModeStatic Driving (Single Pixel Single Control)Static Driving (Single Pixel Single Control)
Encapsulation TypeLight Board & Driving  Board Integrated Light Board & Driving  Board Integrated
Lifespan≥ 100,000.00 hours≥ 100,000.00 hours
Pixel Configuration16bit16bit
Maximum Power Consumption (w/m2)800100010001000
Average Power Consumption (w/m2)350375375375
Control SystemColorlight / NovastarColorlight / Novastar
Input VoltageAC100~240V 50/60HzAC100~240V 50/60Hz
Working Voltage for ModuleDC4.2V ±0.2VDC4.2V ±0.2V
Working TemperatureTemperature   0℃ ~50℃ Temperature   0℃ ~50℃
Working  HumidityHumidity 20%RH ~ 90%RH (Without Condensation)Humidity 20%RH ~ 90%RH (Without Condensation)
Storage TemperatureTemperature  -20℃ ~70℃ Temperature  -20℃ ~70℃
Storage HumidityHumidity 10%RH ~ 95%RH (Without Condensation)Humidity 10%RH ~ 95%RH (Without Condensation)
Protection DegreeIP20IP20
Frame Material//
Installation EnvironmentIndoorIndoor
Packing WayPearl Cotton+Wooden Case/AirboxPearl Cotton+Wooden case/Airbox
